Luminex GigaCore 26i

Pune o întrebare
LU 01 00052
14,756.00 Lei
Stoc furnizor
GigaCore 26i este un switch Gigabit Ethernet care oferă o soluție favorabilă bugetului atunci când densitatea portului este importantă. Unitatea vine cu toate funcționalitățile avansate ale gamei de comutatoare Ethernet GigaCore, într-un pachet complet orientat spre instalare AV. Unitatea oferă 26 de porturi Gigabit care sunt toate conectate pe panoul frontal.
  • Pune o întrebare

GigaCore 26i este un switch Gigabit Ethernet care oferă o soluție favorabilă bugetului atunci când densitatea portului este importantă. Unitatea vine cu toate funcționalitățile avansate ale gamei de comutatoare Ethernet GigaCore, într-un pachet complet orientat spre instalare AV. Unitatea oferă 26 de porturi Gigabit care sunt toate conectate pe panoul frontal. Fiecare port al comutatorului va avea indicații colorate care vor indica diferite proprietăți ale portului, cum ar fi: PoE, redundanță și apartenența la grup.



  • Most suitable applications: Fixed installations
  • RLinkX (Link redundancy): Yes
  • Groups (VLAN segmentation): Yes
  • MultiLinkX (Link aggregation): Yes
  • Profile manager: Yes
  • Memory: 4Mb
  • MAC address table:
  • Address learning / Aging: Self learning, Auto aging
  • Switching throughput: 52Gbps
  • Jumbo frames: MTU up to 9600
  • IGMP support: Yes (V1/V2/V3)
  • IGMP snooping: Yes, enabled by default
  • Port sensing: Auto negotiation
  • Auto crossover: MDI / MDIX
  • Auto sensing: Full or Half Duplex (Gigabit is Full Duplex)



  • Ethernet connectivity: 24 x RJ45 connectors (incl. 4x dual media on ports 21-24)
  • Fiber connectivity: 6 x SFP cages (incl. 4x dual media on ports 21-24)
  • Ethernet port speed: 1Gbps
  • Serial: 1 x serial RJ45 console port



  • Power connectivity:
    • 1 x IEC inlet
    • 1 x redundant power input on Molex Mini-Fit Junior 14 pin connector
  • Power input: 100-240VAC, 50-60Hz
  • Power consumption: Maximum 30W Maximum 430W with PoE
  • Fuse: None
  • Backup power input: 12VDC / 2,5A
  • Backup PoE power input: -54VDC / 6,5A
  • PoE supply: Optional on front ports only (up to 370W)



  • Supported protocols: Avnu AVB/MILAN, Dante©, RAVENNA/AES67©, Ethersound©, Q-SYS/Q-LAN, REAC©, sACN, ArtNet, MANet2, HogNet, RTTrPL (BlackTraX), IEEE 802.1p CoS (Class of Service), DiffServ (DSCP), PoE (802.3af) (optional), PoE+ (optional), IEEE 1588 PTP V2
  • Sound protocol compliance: Yes (low jitter)
  • Ethernet compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3x Flow Control, IEEE 802.3ab Gigabit Ethernet



  • Display and jog: None
  • Configuration: Through the built-in web server
  • Status LEDs:
    • Global status LEDs: Device, power, PoE power, RLinkX and mode
    • Port status LEDs: PoE, MultiLinkX, RLinkX, groups, link/activity and port speed
    • Dark mode available
  • Colored RGB LEDs: Yes



  • Mounting: Rack
  • Enclosure: Robust metal housing
  • Dimensions (W x D x H): 482 x 270,3 x 44 mm (19" x 10,6" x 1,73")
  • Weight: 4 kg
  • Packaging: 545 x 420 x 80 mm (21,5" x 16,5" x 3,15")
  • Environment:
    • Operating temperature: 0 to +50 °C (non-PoE version), 0 to +40 °C (PoE version)
    • Storage temperature: -10 to +70 °C
    • Humidity (non condensing): 5 to 95% RH
  • Noise level @1m:
    • Max 22dBA (Ambient: 0 – 30°C)
    • Max 33dBA (Ambient: 30 – 50°C)
    • Max 22dBA (PoE <150W, Ambient: 0 – 30°C)
    • Max 33dBA (PoE <150W, Ambient: 30 – 40°C)
    • Max 33dBA (PoE <250W, Ambient: 0 – 40°C)
    • Max 33dBA (PoE >250W, Ambient: 0 – 30°C)
    • Max 37dBA (PoE >250W, Ambient: 30 – 40°C)
  • Certificates/Approvals: cSGSus Mark, CE, CB certificate, RoHS
  • Standards: IEC 60950-1, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, FCC Part 15 CFR 47, CAN/ICES-003, EN 55022, EN 55024



  • Product codes:
    • LU 01 00052 (GigaCore 26i)
    • LU 01 00052-POE (GigaCore 26i with PoE supply)
